Orbital Shaker cum BOD Incubator

Product Description

SALIENT FEATURES :

• Stainless steel inner chamber;
• Four square semicircle transition, convenient to clean;
• Micro-computer control system; LCD display with functions of time setting, parameter memorizing and power reset recovering. (Optional)
• CFC-free refrigeration and gentle breeze circulation. (For BOD Shaker Only)
• Double door seal, tempered glass, silicon rubber seal,
• Inner & Outer door with magnetic rubber seal.
• Inner chamber with light for convenient observation.

PRODUCT DETAILS :

Most versatile for Biochemical Oxygen Demand determinations. Castor wheel mounted cabinet is double walled with inner chamber S.S. and outer wall of M.S. Sheet duly powder coated. The gap between the outer and the inner wall is fitted with special grade glass wool to prevent thermal losses. Temp. range 5ᵒC to 60ᵒC (BOD Shaker)with accuracy of ±0.5ᵒC .Unit is fitted with air circulation fans for maintaining temperature uniformity throughout the chamber. Fully view inner glass/Acrylic door permits inspection of specimens, without disturbing the same. Lock and key arrangement is provided in the double walled outer door. Unit is fitted with fluorescent illumination lamp inside the chamber (as per customer requirement). Refrigeration unit is formed by compressor. The front panel is provided with separate indicator lamps-cum-switches for Main, Heating and Cooling. Works on 220 / 230 A.C. supply.

Shaker speed controlled by the speed regulator. Shaking platform made of S.S. accommodate 16 flasks of 500ml (or as per requirements) capacity. Suitable to work 220/230V, 50 Hz. Single Phase A.C. supply.

SPECIFICATIONS :

• Capacity 16 × 500 ml. Flask temp. 5°C above ambient to 60°C.
• Same as LI-BODS-10A but temp. range 5°C to 60°C with lighting arrangement
• To hold 16 flasks 250ml or 500ml

• Timer 0-24 hours
• Digital temp. Indicator-cum-Controller
• Microprocessor PID digital temp. Indicator-cum-controller
• Automatic Voltage Stabilizer 3-5 KVA (Recommended Must.)
