ULTRA SONIC BATH
Product Details:
Product Description
SALIENT FEATURES : :
LIENT FEES APPLICATION
- Continuous self tuning circuitry for any change in work load liquid level and bath temp.
- Uniform cavitations throughout the tank.
- Separate oscillator eliminates damage to generator in case of failure of transducer.
- Using 40 Khz frequency for effective cleaning with low noise
- Designed for complete cleaning of small and large components without dismantling.
- Inner tank and outer body made of stainless steel
PRODUCT DETAILS :
The Ultrasonic energy is produced by converting electrical energy in to Mechanical Vibrations by using generator and piezo Electric Transducers. Due to Mechanical Vibrations in cleaning liquid this Phenomenon is called cavitations. In a very short time it removes all dirt & foreign bodies from components which are immersed in the cleaning liquid.
Technical Specification
| Model Number | LI -USB-14 |
| Material | Stainless Steel |
| Shape | 175 * 165 * 200 |
| Capacity | 1.8 ltr. |
| Usage/Application | removes all dirt & foreign bodies from components |
SPECIFICATIONS :
| Model | LI-USB-14 A | LI-USB-14 B | LI-USB-14 C | LI-USB-14 D | LI-USB-14 E |
| Make | LABARD | ||||
| Tank Volume (liters) | 1.8 ltr. | 2.5 ltr. | 4 ltr. | 6 ltr. | 9 ltr. |
| Ultrasonic Wattage | 50 W | 100 W | 150 W | 200 W | |
| Ultrasonic Frequency | 40 ± 3 KHz | ||||
| Tank Dimension (Taper) L x W x H in mm | 150 x 137 x 100 | 150 x 137 x 150 | 235 x 135 x 150 | 300 x 153 x 150 | 300 x 240 x 150 |
| Outer Dimension (L x W x H / mm) | 175 x 165 x 200 | 175 x 165 x 250 | 265 x 165 x 290 | 325 x 175 x 290 | 325 x 265 x 290 |
| Heating | Ambient to 800 C Digitally Controlled (Dual Display) | ||||
| Digital Timer | 5 to 60 Minutes | ||||
| Tank Drain | N/A | Ball Valve | |||
| Inner Tank Material | Stainless Steel | ||||
| Outer Housing Material | Stainless Steel | ||||
| Power Supply | 220 Volt, AC 50 Hz, Single Phase | ||||
| Model | LI-USB-14 F | LI-USB-14 G | LI-USB-14 H |
| Make | LABARD | ||
| Tank Volume (liters) | 12 ltr. | 16 ltr. | 25 ltr. |
| Ultrasonic Wattage | 200 W | 300 W | 600 W |
| Ultrasonic Frequency | 40 ± 3 KHz | ||
| Tank Dimension (Taper) L x W x H in mm | 300 x 240 x 200 | 330 x 300 x 200 | 500 x 300 x 200 |
| Outer Dimension (L x W x H / mm) | 325 x 265 x 340 | 354 x 325 x 340 | 530 x 430 x 320 |
| Heating | Ambient to 800C Digitally Controlled (Dual Display) | ||
| Digital Timer | 5 to 60 Minutes | ||
| Tank Drain | Ball Valve | ||
| Inner Tank Material | Stainless Steel | ||
| Outer Housing Material | Stainless Steel | ||
| Power Supply | 220 Volt , AC 50 Hz, Single Phase | ||
